Prysmian Grey 3-core & earth Cable 1mm² x 25m
Product details
Product information
This harmonised grey PVC twin and earth cable will power your home in style. Boasting easy-to-strip, lead-free copper cores in complementary colours, it's ideal for lighting up living rooms and powering kitchen appliances. Rated to 300V for single phase and 500V for three phase, with a 25m length, it's perfect for any domestic circuit. Supple yet durable, this cable makes wiring a breeze while ensuring safety and reliability for years to come.
Features and benefits
- Harmonised core colours
- Easy to strip, lead-free cable
- Mains electricity cable
- Ideal for lighting and switching circuits
- Easy to strip
- Maximum voltage for 3-phase is 500V.
- Maximum voltage for single phase is 300V.
- Current rating is based on single phase clipped direct method in BS7671
Specifications
| Amp rating | 16A |
|---|---|
| Brand | Prysmian |
| Cable code | 6243YH |
| Cable length | 25m |
| Colour | Grey |
| Conductor area | 1mm² |
| Maximum operating temperature | 70°C |
| Minimum operating temperature | -15°C |
| Number of cores | 3 |
| Number of pieces | 1 |
| Number of wire strands | 1 |
| Outer sheath material | PVC |
| Pack quantity | 1 |
| Sheath properties | Standard |
| Shield material | Unshielded |
| CPC conductor area | 1mm² |
| Circuit protective conductor (CPC) | With CPC |
| Number of CPC cores | 1 |
| Product code | 5019325301834 |
Reviews
4 / 5(5 reviews)Big mon - 5 / 5 - 16/04/2024
Very good and easy to use.
Done just what I wanted it for, you can’t ask for more.
mickbenne1 - 4 / 5 - 08/11/2017
General PVC Cable
This cable being a general range within the PVC/PVC 6243Y found useful to obtain a reasonably shorter length than normally required. Whilst being used to trade costing during my lifetime found cost to be commensurate with retail-supply & demand.
phlute - 4 / 5 - 06/04/2014
Perfect for adding a two way switch
I needed to add a second switch in the garage and this wring is perfect for adding the capability to an existing installation. Wires stripped easily. The wire bundle was nicely flexible enabling me to route it neatly around the walls.
peterrr - 4 / 5 - 28/03/2013
cable
All fine, and useful to have "reserve and collect".
Smudge - 3 / 5 - 17/07/2012
Cable OK, insulation not easy-strip
While the quality of the cable seems fine, the supposed easy-strip insulation is not that easy. It was very time consuming to strip back a relatively short length, despite having pre-scored it. Trying to ease back another 30mm of installed cable to ease space in the pattress was nowhere near as straightforward as with cables such as BICC. However, if time isn't of the essence, the value for money is OK. I wouldn't want to be on site using it.
